Clinical and histopathological features resembling those of human focal segmental glomerulosclerosis in a cat with nonimmune-mediated glomerulonephropathy

  • Go Sugahara1,
  • Satoshi Hosaka2,
  • Takayuki Mineshige1,
  • Junichi Kamiie1 and
  • Kinji Shirota1Email author
BMC Veterinary Research201511:251

https://doi.org/10.1186/s12917-015-0569-4

©  Sugahara et al. 2015

Received: 5 March 2015

Accepted: 30 September 2015

Published: 6 October 2015

Abstract

Background

Nonimmune-mediated glomerulonephropathies are rarely reported in domestic animals with the exception of amyloidosis. Here we describe the pathological features and clinical course of a feline with protein-losing nonimmune-mediated glomerulonephropathy characterized by segmental glomerulosclerosis and severe podocyte injury.

Case presentation

A castrated male Japanese domestic cat aged 3 years and 8 months had hypertension, persistent proteinuria, and azotemia. Microscopic examination of a renal biopsy revealed many glomeruli with adhesion to the Bowman’s capsule and segmental sclerosis. The most characteristic ultrastructural glomerular feature was severe podocyte foot process effacement. No electron-dense deposits were observed. Immunofluorescence revealed no immune deposits, but abnormal expression of nephrin and podocin was detected in the glomeruli. These findings resemble those of human focal segmental glomerulosclerosis. The cat temporarily responded to treatment with angiotensin-converting enzyme inhibitors and prednisolone administration but died of progressive renal failure 32 months after biopsy.

Conclusions

The cat was diagnosed with nonimmune mediated glomerulonephropathy because of the absence of immune deposits and severe podocyte injury. To our knowledge, this is the first report of nonimmune-mediated glomerulonephropathy in a cat resembling human focal segmental glomerulosclerosis.

Keywords

CatRenal biopsyGlomerulonephropathyFocal segmental glomerulosclerosis

Background

Immune-mediated glomerulonephritis has been reported in dogs and cats as a common renal disease that causes chronic renal failure [1]; however, with the exception of amyloidosis, nonimmune-mediated glomerulonephropathies are rarely reported in domestic animals. Here we describe the pathological features and clinical course of a cat with protein-losing nonimmune-mediated glomerulonephropathy characterized by segmental glomerulosclerosis and severe podocyte injury.

Case presentation

This Japanese domestic cat was a castrated male aged 3 years and 8 months with anorexia, weight loss, and polyuria/polydipsia for a few months. Clinical examinations before treatment and renal biopsy revealed a heart murmur, hypertension (systolic blood pressure of 220 and 160 mmHg at 10 and 5 days before biopsy, respectively), renal enlargement, and abnormalities of blood biochemistry and urinalysis, such as azotemia (Fig. 1) and persistent proteinuria (a urinary protein-to-creatinine ratio of 2.19 and 300–1000 mg/dL protein level using reagent strips).
Figure 1
Fig. 1

Treatment and changes in the levels of blood urea nitrogen (BUN) and serum creatinine (Cre) during the disease course

Two-third of the renal biopsy tissue obtained from the cat was fixed in 10 % neutral-buffered formalin and embedded in paraffin wax. After processing, sections (3 μm) were stained with hematoxylin and eosin (HE) and periodic acid-Schiff (PAS) for histological examination. For immunofluorescence (IF) using goat anti-nephrin (Santa Cruz Biotechnology, Santa Cruz, CA) or rabbit anti-podocin (Sigma-Aldrich, St Louis, MO, USA) antibodies, dewaxed sections were pretreated with Target Retrieval Solution, pH 9.0 (Nichirei Corp., Tokyo, Japan) at 121 °C for 5 min in an autoclave for nephrin or with trypsin (Sigma; T7168) at 37 °C for 30 min for podocin. The secondary antibodies were Alexa Fluor 488-conjugated rabbit anti-goat immunoglobulin (Ig)G (Invitrogen, Tokyo, Japan) or Alexa Fluor 488-conjugated goat anti-rabbit IgG (Invitrogen). Renal tissue from a 10-year-old female mixed breed cat with mild and focal interstitial nephritis was used for comparison.

A small piece of fresh biopsy tissue was embedded in an optimal cutting temperature compound (Sakura Finetek, Tokyo, Japan). Cryosections and paraffin sections were prepared to detect immune deposits. Direct IF studies using fluorescein isothiocyanate (FITC)-conjugated anti-cat IgG (Kirkegaard & Perry Laboratories, Inc., Gaithersburg, MD, USA) and indirect immunostaining using anti-cat C3 primary antibodies (Biogenesis, Poole, UK) and FITC-conjugated secondary antibodies (Chemicon, Temecula, California) were performed. An FSX100 fluorescence microscope (OLYMPUS, Tokyo, Japan) was used for examination.

For ultrastructural examination, another small piece of the biopsy tissue was fixed in 2.5 % glutaraldehyde and postfixed in 1 % OsO4. Fixed specimens were then dehydrated using ascending grades of alcohol and embedded in epoxy resin. Ultrathin sections were stained with uranyl acetate and lead citrate and observed using a JEOL 1210 transmission electron microscope (JOEL, Tokyo, Japan) at 80 k.

The treatment and levels of blood urea nitrogen (BUN) and serum creatinine (Cre) during the disease course are shown in Fig. 1. After renal biopsy, the administration of a sustained course of angiotensin-converting enzyme (ACE) inhibitor (benazepril, Novartis Pharma K.K., Tokyo, Japan) and a tapering course of prednisolone were immediately started. For approximately 1 year, the levels of BUN and Cre were decreased. However, approximately 15 months later, both levels gradually began to increase. Amlodipine and prednisolone were administered without any noticeable effect. The cat died from the progression of renal failure with anorexia and anemia approximately 32 months after renal biopsy. During the disease course, persistent proteinuria (30–100 mg/dl using reagent strips) was observed despite treatment. Necropsy was not allowed by the owner.

Microscopically, the biopsy specimen contained 12 glomeruli with the following characteristics: one showed global sclerosis (8.3 %), four (33.3 %) showed adhesion to the Bowman’s capsule, and four (33.3 %) showed segmental sclerosis with increased matrix (Fig. 2). The regions without sclerosis or adhesion in these affected glomeruli and the remaining three (25 %) glomeruli appeared normal, except for occasional hyaline droplets in the podocytes. Diffuse mononuclear-cell infiltration and fibrosis were observed in the interstitium.
Figure 2
Fig. 2

Light microscopic features of the biopsy specimen: (a) low magnification and (b to d) high magnification images of the glomeruli. Infiltration of lymphocytes and plasma cells in the interstitium, severe interstitial fibrosis and tubular atrophy were observed (a). The glomeruli show global sclerosis (b), multiple adhesion to Bowman’s capsule (c: arrowheads), segmental sclerosis with increased matrix and adhesion (d: arrowheads) and occasional hyaline droplets in podocyte cell bodies (d: arrow). Periodic acid-Schiff stain. Scale bars: 30 μm

Examination using transmission electron microscopy revealed a distinct lesion in the glomeruli characterized by severe and global foot process (FP) effacement without electron-dense deposits, and there were no obvious glomerular basement membrane (GBM) abnormalities or cellular infiltration (Fig. 3) The podocytes had global changes such as cytoplasmic vacuolation, the formation of tight junctions between FPs, and microvilli formation on the free surface.
Figure 3
Fig. 3

Transmission electron microscopic features of the biopsy specimen: (a) low and (b) high magnifications of a region in the frame in (a). Severe and global foot process effacement (arrowheads), vacuolization (asterisks), formation of microvilli (arrows), and tight junctions between foot processes (white arrowheads) are observed. CL, capillary lumen; Ed, endothelial cell; FP, foot process; GBM, glomerular basement membrane; Me, mesangial cell; Po, podocyte; US, urinary space. TEM, transmission electron microscopy. Scale bars: 2 μm

Immunohistochemical analysis did not detect the deposition of IgG and C3 in the glomeruli (Fig. 4). In the normal cat glomeruli, the labeling of nephrin and podocin exhibited a sharp, linear pattern along the GBM, as previously reported. In contrast, in the present case, the expression of those proteins was decreased, and the labeling pattern was granular (Fig. 5).
Figure 4
Fig. 4

Immunofluorescence analysis of IgG and C3 expression in the glomeruli. No signal for feline IgG (a) and C3 (b) was observed in the glomeruli. Scale bars: 30 μm

Figure 5
Fig. 5

Immunofluorescence analysis of nephrin and podocin expression in the glomeruli. Expression of nephrin and podocin (c and d) was decreased, and staining exhibited a coarse granular pattern compared with the sharp linear pattern of normal glomeruli (a and b). Scale bars: 30 μm

Discussion

We regarded this renal biopsy case as a primary glomerulonephropathy with tubulointerstitial changes. Although the light microscopic findings were similar to those of chronic interstitial nephritis (CIN), which is the most common renal disease of cats [2–4], feline CIN commonly develops in animals older than this one and is not accompanied by persistent proteinuria. Podocyte injury is closely related to proteinuria, and persistent proteinuria causes tubulointerstitial injury as a common mechanism of proteinuric nephropathy in humans and animals [3–5]. Nephrin and podocin are expressed in FPs and slit diaphragms and play a critical role in selective filtration. Altered expression of these proteins indicates podocyte injury related to proteinuria in humans and in animal models [6–8]. Therefore, in addition to ultrastructural changes, decreased expression and the altered expression pattern of nephrin and podocin indicate that podocyte injury and dysfunction likely occurred as a primary event in the present case.

The histopathological, IF, and electron microscopic findings suggested nonimmune-mediated pathogenesis in the present case. Nonimmune-mediated glomerulonephropathy related to podocyte injury in cats has been rarely reported, and to our knowledge, there is only one report of minimal-change glomerulopathy in a cat [9] in which the renal glomeruli show severe FP effacement without glomerulosclerosis. In the present study, the glomeruli showed irreversible lesions such as adhesion and sclerosis as well as severe podocyte injury, and these morphological changes resemble those of human focal segmental glomerulosclerosis (FSGS). FSGS is a major cause of nephrotic syndrome and subsequent progression to end-stage renal disease in humans [10, 11], which was also reported in a dog [12].

The diagnosis of FSGS is based on the following light microscopic findings: glomerular sclerosis and tuft collapse are focal (some glomeruli, but not all) and segmental (a segment of the glomerulus is affected). However, in practice, diffuse or global glomerulosclerosis is sometimes observed in human and canine FSGS and its animal models, depending on the disease stage [8, 12, 13]. Therefore, the renal disease in the present case may be more advanced stage of FSGS, because of high frequency of affected glomeruli and tubulointerstitial lesions in association with renal failure.

The key pathogenic mechanism of FSGS is the progressive damage of podocytes and their detachment from the GBM followed by capillary tuft adhesion to the Bowman’s capsule and sclerosis [10, 11]. FSGS encompasses a number of clinicopathologic syndromes sharing this common glomerular lesion, including primary (or idiopathic) and secondary FSGS (related to a variety of causes). Hypertension is an important underlying comorbidity in humans with secondary FSGS [13]. However, hypertension in the present case might have been caused by chronic renal failure, and its relationship to the pathogenesis of FSGS is unclear because of the lack of long-term monitoring of blood pressure.

FSGS in humans is less responsive to steroid therapy [11, 14]. Here the cat temporarily responded to an ACE inhibitor and steroid therapy but died due to the progression of renal failure. However, as previously mentioned, renal function was diminished at the time of renal biopsy, and we were therefore unable to evaluate the exact therapeutic effect.

Conclusions

This case report demonstrates the importance of examination of renal biopsies using IF and electron microscopy as well as light microscopy. Moreover, to our knowledge, this is the first report of nonimmune-mediated glomerulonephropathy in a cat that resembles human FSGS.

Abbreviations

HE:

Hematoxylin and eosin

PAS:

Periodic acid-Schiff

IF:

Immunofluorescence

BUN:

Blood urea nitrogen

Cre:

Creatinine

ACE:

Angiotensin-converting enzyme

FP:

Foot process

GBM:

Glomerular basement membrane

CIN:

Chronic interstitial nephritis

FSGS:

Focal segmental glomerulosclerosis

Declarations

Acknowledgements

This Research was partially supported by a research project grant (2014 K05) awarded by the Azabu University.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated.

Authors’ Affiliations

(1)
Laboratory of Veterinary Pathology, School of Veterinary Medicine, Azabu University, Sagamihara, Japan
(2)
Hosaka Animal Hospital, Sagamihara, Japan

References

  1. Dennis JC, Stephen PD, Patricia AS. Diseases of the Glomerulus. In: Canine and Feline Nephrology and Urology. 2nd edition. Edited by Dennis JC, Stephen PD, Patricia AS. Saunders, St. Louis; 2011. P. 218–39.Google Scholar
  2. Ichii O, Yabuki A, Sasaki N, Otsuka S, Ohta H, Yamasaki M, et al. Pathological correlations between podocyte injuries and renal functions in canine and feline chronic kidney diseases. Histol Histopathol. 2011;26(10):1243–55.PubMedGoogle Scholar
  3. Jepson RE, Brodbelt D, Vallance C, Syme HM, Elliott J. Evaluation of predictors of the development of azotemia in cats. J Vet Intern Med. 2009;23(4):806–13.View ArticlePubMedGoogle Scholar
  4. Lawson J, Elliott J, Wheeler-Jones C, Syme H, Jepson R. Renal fibrosis in feline chronic kidney disease: Known mediators and mechanisms of injury. Vet J. 2014;203(1):18–26.View ArticlePubMedGoogle Scholar
  5. Zoja C, Abbate M, Remuzzi G. Progression of renal injury toward interstitial inflammation and glomerular sclerosis is dependent on abnormal protein filtration. Nephrology, Dialysis, Transplantation 2014; doi: 10.1093/ndt/gfu261.
  6. Agrawal V, Prasad N, Jain M, Pandey R. Reduced podocin expression in minimal change disease and focal segmental glomerulosclerosis is related to the level of proteinuria. Clin Exp Nephrol. 2013;17(6):811–18.View ArticlePubMedGoogle Scholar
  7. Kim BK, Hong HK, Kim JH, Lee HS. Differential expression of nephrin in acquired human proteinuric diseases. Am J Kidney Dis. 2002;40(5):964–73.View ArticlePubMedGoogle Scholar
  8. Wharram BL, Goyal M, Wiggins JE, Sanden SK, Hussain S, Filipiak WE, et al. Podocyte depletion causes glomerulosclerosis: diphtheria toxin-induced podocyte depletion in rats expressing human diphtheria toxin receptor transgene. J Am Soc Nephrol. 2005;16(10):2941–52.View ArticlePubMedGoogle Scholar
  9. Backlund B, Cianciolo R, Cook A, Clubb F, Lees G. Minimal change glomerulopathy in a cat. J Feline Med Surg. 2011;13(4):291–5.View ArticlePubMedGoogle Scholar
  10. D'Agati VD. Pathobiology of focal segmental glomerulosclerosis: new developments. Curr Opin Nephrol Hypertens. 2012;21(3):243–50.View ArticlePubMedGoogle Scholar
  11. Gbadegesin R, Lavin P, Foreman J, Winn M. Pathogenesis and therapy of focal segmental glomerulosclerosis: an update. Pediatr Nephrol. 2011;26(7):1001–15.PubMed CentralView ArticlePubMedGoogle Scholar
  12. Aresu L, Zanatta R, Luciani L, Trez D, Castagnaro M. Severe renal failure in a dog resembling human focal segmental glomerulosclerosis. J Comp Pathol. 2010;143(2–3):190–4.View ArticlePubMedGoogle Scholar
  13. D'Agati VD, Kaskel FJ, Falk RJ. Focal segmental glomerulosclerosis. N Engl J Med. 2011;365(25):2398–411.View ArticlePubMedGoogle Scholar
  14. Fogo AB. Causes and pathogenesis of focal segmental glomerulosclerosis. Nat Rev Nephrol. 2014;11(2):76–87.View ArticlePubMedGoogle Scholar
